Critical Industry Solutions
Serving aerospace, automotive, petrochemical, and power generation sectors with precision inspection of critical components including:
• Disks and rings
• Forgings and castings
• Composite structures (carbon fiber, honeycomb core, etc.)
• Bars, tubes, and billets
• Custom-shaped parts
| Parameter | Specification |
| Suitable Diameter (Pipes/Rods) | 30-800mm (Multiple units required for large span ranges) |
| Suitable Diameter (Discs/Rings) | 55-1200mm |
| Suitable Workpiece Shapes | Pipes, Rods, Discs, Rings |
| Straightness Requirement | ≤2mm/m |
| Surface Requirement | Smooth and burr-free surface |
| Material Compatibility | Metals capable of ultrasonic wave transmission |
| Applicable Processes | Forging, Powder metallurgy, etc. |
| Detectable Defects | Transverse/Longitudinal/delamination defects; Thickness measurement |
| Signal-to-Noise Ratio | 16dB |
| Missed Detection Rate | 0% |
| False Alarm Rate | 0% |
| Dead Zone | 0 |
| Additional Functions | Real-time audio/visual alarms; Automatic data/C-scan image storage; Report generation |
| Power Supply | 380V (Customizable to country-specific standards) |
| Inspection Speed | 0-8m/min (Complies with testing standards) |
1. Advanced Multi-Channel System
Independent ultrasonic pulser/receiver cards
High-precision signal acquisition & processing
2. Precision Motion Control
Multi-axis, multi-degree-of-freedom positioning
Driven by high-performance CNC motors
3. Superior Imaging Capabilities
High-resolution imaging with wide frequency bandwidth
4. Intelligent Flaw Analysis
Automatic defect identification, positioning, quantification, and imaging
5. Versatile Applications
Disks • Rings • Bars • Tubes • Billets • Diverse components
Expert Support, Customized Solutions, Go above and beyond: Welcome to NCS's World of Non-Destructive Testing.
