Tubes & Bars Inspection Solutions
Precision testing systems serving:
Metallurgy • Steel • Machinery • Power Generation • Aerospace • Nuclear • Oil & Gas • Boiler Industries
Global Compliance Assurance
Certified to key international standards:
API SPEC 5L • API SPEC 5CT • ASTM 213M • ASTM A106 • ASTM A519
| Parameter | Specification |
| Suitable Diameter | 100-1500mm (Multiple units required for large span ranges) |
| Suitable Workpiece | Pipes/Rods |
| Straightness Requirement | ≤4mm/m |
| Surface Requirement | No requirement |
| Material Compatibility | Metals capable of ultrasonic wave transmission |
| Applicable Processes | Hot-rolled, Cold-drawn, Cold-rolled, etc. |
| Detectable Defects | Transverse/Longitudinal/delamination defects; Thickness measurement |
| Wall Thickness (Pipes) | ≤150mm |
| Missed Detection Rate | 0% |
| False Alarm Rate | 0% |
| Dead Zone | 0 |
| Marking Accuracy | ≤50mm (Speed-dependent) |
| Additional Functions | Real-time audio/visual alarms; Automatic data/image storage; Report generation |
| Power Supply | 380V (Customizable to country-specific standards) |
| Water Consumption | ~5m³/h (Subject to actual configuration) |
| Compressed Air | 0.4~0.6MPa (Subject to actual configuration) |
| Inspection Speed | 0-10m/min (Complies with testing standards) |
1. Comprehensive Flaw Detection Platform
Complete longitudinal, transverse, oblique, and lamination/thickness testing (longitudinal & transverse waves) in a single scan operation.
2. Adaptable Probe Solutions
Water film, bag, or jet coupling methods
Effortless probe configuration
3. Advanced Drive System
Infinitely adjustable speed control
Enhanced signal stability technology
4. High-Resolution Scanning Performance
Exceptional sensitivity with optimized SNR
Accommodates ultra-large diameter workpieces
5. Core Applications
Tubes • Cylinders • Bars
Expert Support, Customized Solutions, Go above and beyond: Welcome to NCS's World of Non-Destructive Testing.
