Seamless Pipes & Bars Precision Inspection Services
Providing critical quality assurance for the metallurgy, machinery manufacturing, power generation, aerospace, nuclear energy, oil & gas, boiler, and associated industries. Ensures product integrity and operational safety.
Rigorous Compliance with International Standards
Strictly adheres to API SPEC 5L, API SPEC 5CT, and relevant ASTM standards (including ASTM 213M, A106, A519, and others), delivering compliant and reliable inspection results.
| Parameter | Specification |
| Suitable Diameter | 30-600mm (Multiple units required for large span ranges) |
| Suitable Workpiece | Pipes/Rods |
| Straightness Requirement | ≤4mm/m |
| Surface Requirement | No requirement |
| Material Compatibility | Metals capable of ultrasonic wave transmission |
| Applicable Processes | Hot-rolled, Cold-drawn, Cold-rolled, etc. |
| Detectable Defects | Transverse/Longitudinal/delamination defects; Thickness measurement |
| Missed Detection Rate | 0% |
| False Alarm Rate | 0% |
| Dead Zone | 0 |
| Marking Accuracy | ≤100mm (Speed-dependent) |
| Additional Functions | Real-time audio/visual alarms; Automatic data/image storage; Report generation |
| Power Supply | 380V (Customizable to country-specific standards) |
| Water Consumption | ~5m³/h (Subject to actual configuration) |
| Compressed Air | 0.4~0.6MPa (Subject to actual configuration) |
| Inspection Speed | 0-15m/min (Complies with testing standards) |
1. Adaptable to Low-Prep Surfaces
Ideal for inspecting hot-rolled mill scale and cold-drawn surfaces with minimal cleaning requirements.
2. Optimized Detection Efficiency
Ensures high acoustic coupling for stable, repeatable results
Features low-maintenance design with rapid setup adjustments
3. Comprehensive Flaw & Thickness Scanning
Simultaneously detects longitudinal, transverse, and oblique flaws while measuring thickness/laminations (utilizes longitudinal and transverse wave modes).
4. Targeted Industry Solutions
Essential for boiler pipes • nuclear power tubing • upset drill pipes • critical component bar stock
Expert Support, Customized Solutions, Go above and beyond: Welcome to NCS's World of Non-Destructive Testing.
